Tablet Bottle Packing Machine
A Tablet Bottle Packing Machine automates the process of counting, filling, sealing, capping, and packaging tablets into bottles. Pharmaceutical, nutraceutical, healthcare, and dietary supplement manufacturing facilities usually use this machine for maintaining product quality.
This machine combines several packaging functions into one integrated system. Tablets are counted through electronic counting sensors before being transferred into bottles with high accuracy. The production speed of this machine ranges from 30 to over 150 bottles per minute, depending on bottle size and tablet count.
Need a Cutsom Quote
Or More information About this product? Contact our sales stuff today!
Key Features
Technical Data
FAQ
Machine Parts Name
Applied Tablet Bottle Types
Reviews No reviews yet
- Multi-Channel Counting System: Multiple counting channels allow several product streams to be processed simultaneously. This increases production output and improves overall packaging efficiency.
- PLC and Touchscreen Controls: Operators can adjust counting parameters, bottle specifications, and production speed through an HMI interface. It simplifies machine operation and monitoring.
- Automatic Rejection System: Bottles with incorrect counts, missing caps, or packaging defects can be automatically removed from the production line.
- Technical Support and Spare Parts Service: After purchase, you get installation assistance, operator training, and spare parts availability. Moreover, there’s also a one-year warranty for manufacturers.
- Flexible Line Integration: You can integrate bottle unscramblers, capping machines, induction sealers, labeling systems, and cartoners with the machine. This allows manufacturers to build a complete automated bottling line.
| Parameter Category | Specification / Range |
| Production Line Output: | 40 – 180 bottles/min |
| Applicable Dosage Forms: | Tablets (round, ball), pills, soft/hard capsules, and other solid particles |
| Applicable Tablet/Capsule Size: | Diameter Φ2 – Φ25 mm |
| Applicable Bottle Diameter: | Φ15 – Φ125 mm |
| Applicable Bottle Height: | 30 – 200 mm |
| Power Supply: | Three-phase 380V / 50Hz (customizable) |
| Total Line Power: | Approx. 5 – 15 kW (depending on configuration) |
| Air Supply Requirement: | Pressure: 0.6 – 0.8 MPa, Air Consumption: approx. 0.6 – 1.2 m³/min |
| Overall Line Dimensions (Reference): | Approx. 8000 × 2000 × 1600 mm (L × W × H) |
It is mainly used for automatic packaging of round/oval plastic & glass bottles filled with tablets, capsules, pills, softgels, granules, effervescent tablets in pharmaceutical, health food, vitamin industries.
Standard range: 10–500ml plastic/glass bottles.
Yes.
The machine is equipped with pre-screening vibrating feeder to separate fragments and dust before counting. Broken pieces will be filtered out automatically to avoid counting errors.
- Small semi-automatic model: 10–30 bottles/min.
- Full automatic integrated line: 30–120 bottles/min.
Yes. Support 220V/380V 50Hz for most countries; 110V 60V customized version for North America, Southeast Asia. Air compressor matching pressure: 0.6–0.8 Mpa.
12-month full machine warranty.
Yes. We can arrange engineers for on-site machine installation.
